Unlimited Hot Water on Demand
Whole Home Solution
Performance Up to 3.8 Gallons Per Minute (GPM)
Dimensions: 15.20 H x 10.20 W x 3.70 D

APPEARANCE
- Color AppearanceDiamond Gray
- InstallationWall Mounted
CAPACITY
- Capacity3.8 Gallons Per Minute (GPM)
FEATURES
- Activation Flowrate (GPM)≤ 0.5
- Cold/hot water connections (inches)3/4" Cold Water Inlet; 3/4" Hot Water Outlet
- ConfigurationSpace Saver
- ControlsAdjust degree Fahrenheit/CelsiusAdjustable TemperatureDigital Electronic Control
- Flowrate (GPM) @ 37 F inlet2
- Flowrate (GPM) @ 42 F inlet2.09
- Flowrate (GPM) @ 47 F inlet2.29
- Flowrate (GPM) @ 52 F inlet2.4
- Flowrate (GPM) @ 57 F inlet2.59
- Flowrate (GPM) @ 62 F inlet2.9
- Flowrate (GPM) @ 67 F inlet3.4
- Flowrate (GPM) @ 72 F inlet3.79
- Flowrate (GPM) @ 77 F inlet4.5
- Fuel TypeElectric
- Installation LocationIndoor
- Integrated Safety DevicesFlow sensor. High limit thermostat (on each heating element). Inlet Temperature Sensor. Material Rated for Ignition Containment. Outlet Temperature Sensor.
- Max. operating pressure (psi)150
- Max: operating pressure (psi)150
- Maximum Outlet Temperature (F)140
- Min. operating pressure (psi)25
- Point of UseWhole Home
- Product TypeElectric Tankless
- Temperature adjustment amount (degree)1
- Temperature Setting86-140° F Range
- Temperature Setting Factory Default105° F
- Uniform Energy Factor (UEF)>0.91
- Water Connection LocationBottom
POWER / RATINGS
- Amps75.0
- Electrical Circuit Required40 Amp (x2)
- Electrical Requirements240V ; 80A
- First Hour Delivery GPH120
- Hertz60
- Power Rating-kW18
- Voltage (MAX)240 V
WARRANTY
- Labor WarrantyNo Warranty
- Parts Warranty5-Year ReplacementReturn to Vendor
- Warranty NotesSee written warranty for full details
WEIGHTS & DIMENSIONS
- Approximate Shipping Weight15.2 lb
- Net Weight14.09 lb
- Overall Depth3.70 in
- Overall Height15.20 in
- Overall Width10.20 in
- Product Diameter10.200 in
- Product Height (to top of unit)15.200 in
